+ Admotec manufacturs Rotasyn : Special Resolver
   which other makersare not making.

+ Rotasyn can be used in very harsh environments
   like high temperature, strong vibration, high pressure, etc.


   MOC-Mitaka is akting as Admotec Tokyo.
 Admotec 1X-VR Resolver Rotasyn made in Switzerland , 1X-BRX Brushless Resolver Equivalent

  Admotec Tokyo Office Patented in EC & USA
JIS Q 9100: 2009, EN9100:2009, AS9100 Rev.c, ISO 9001:2008

                  Top Pictures are sowing :         Left - Encoder kit       Center - Housing type Resolver       Right - Ring type Resolvers

    Rotasyn has two time reliability compared with a conventional resolver with a rotor made with 3 coils.
    The rotor of Rotasyn is made of solid magnetic metal, therefore, 3 coils are used only for the stator
    while conventional ones have 3 + 3 = 6 coils per unit.
  Application
VR-1X Resolver, Admotec Tokyo, MOC_Mitaka VR-1X Resolver, Admotec Tokyo, MOC_Mitaka VR-1X Resolver, Admotec Tokyo, MOC_Mitaka VR-1X Resolver, Admotec Tokyo, MOC_Mitaka
Aerospace Racing Car Marine Heavy Industry

VR-1X Resolver, Admotec Tokyo, MOC_Mitaka VR-1X Reslover, Admotec Tokyo, MOC_Mitaka Oil Drilling Nuclear Power Generation
Rotasyn is 1X BRX equivalent type resolver but the rotor is made of solid metal without coils. Therefore, reliability is very high.

Operating Temerature Range  (depnds on condition)
(1) Ring type : Standard :   -40 ℃ ~ +135 ℃
High temp. type :   -70 ℃ ~ +200 ℃
(2) Housing type : Standard :   -40 ℃ ~ +150 ℃
High temp. type :   -60 ℃ ~ +230 ℃
(3) Multi-speed type : -200 ℃ ~ +250 ℃
